Sale!
Halo Max Bravo Drive Shower Cheap
Home / Outdrives and Accessories / Halo Max Bravo Drive Shower Cheap

Halo Max Bravo Drive Shower Cheap

Original price was: $189.00.Current price is: $75.60.

For orders under $60.00, a shipping fee of $9.99 applies.
Fast delivery, satisfaction guaranteed.
Secure Payment.
SKU: SK0020667 Category: Tag:
Share

Halo Drive Shower for SE121 drives. Easy installation with no drilling required. Can reduce the upper unit by 50 degrees F.

Additonal Info On This Product:

INSTRUCTIONS FOR INSTALLING A HALO MAX® ON A BRAVO

  • 1. Remove black plastic caps, nuts and washers from each lift ramassembly.
  • 2. Spread legs of Shower, align holes in the brackets over the lift ramshaft. Replace nuts and caps.
  • 3. Lean Drive Shower forward and remove bolt and washer from bearingcap.
  • 4. Place spacer (provided) over that hole.
  • 5. Insert bolt (provided) through the top mounting tab, through thespacer and screw the bolt into the bearing cap until snug.
  • 6. Install nuts onto lift ram assemble. DO NOT re-install washers.Tighten nuts and bolt to 30 ft. / lbs.

Additional step for installing a Halo© on a drive with Latham or Imcosteering that attaches to the “Back Inspection Cap”To remove the top left stud from the drive, use a 3/8”-24 nut as a jam nut.Tighten the two nuts together so that you can place a socket over the jamnut and onto the original nut. Loosen both nuts at the same time.
